High Flow Controller provides high flow for all

Do you want to run flow-intensive tools at the same time as a tiltrotator, but have only one circuit for hammer hydraulics? Then Rototilt’s patented High Flow Controller, HFC, is just what you need. Tiltrotator functions are maintained at reduced speed. The solution is completely unique and creates smart opportunities that have previously been impossible due to the limitations of the technology.

With our optional High Flow Controller you can control a large compactor, sweeper roller or any other flow-intensive tool in a single direction at the same time as a tiltrotator.

The oil is intelligently distributed between the tool and tiltrotator for simultaneous operation. The operator controls the oil flow proportionally in our ICS, up to 200 litres/minute in one direction. At full flow, the speed of the tiltrotator functions is reduced to about half the normal speed.



Benefits

  • Utilisation of high flow in parallel with tiltrotator functions
  • Simple and patented solution
  • Integrated with Innovative Control System, ICS



Requirements

  • Tiltrotator with High Flow Swivel, HFS. Models R4, R5, R6 or R8
  • ICS version 2.8.0 or later
  • Connection SAE-1", PSI 6000 and 24 V on base machine



Read about ICS’s smart functions below.

Secure Lock™

Safe tool handling with SecureLock – yet another of our technical breakthroughs

Find out more about SecureLock

Rototilt® Positioning Solution

Right position at any angle. Integrate RPS with your grade control system for unique precicion and maximum efficiency.

Read more

Pulse function - Spread material automatically

The pulse function is a smart adjustable solution that helps you to quickly and efficiently spread material.

Find out more

Wheel and track control with joystick

With wheel or track control, you can manoeuvre the excavator with the same handle as for excavation and control of your tiltrotator from Rototilt.

Find out more

Electric swivel - Use more advanced tools

Via an electric swivel, you can control tool valves in your tiltrotator system. You can then easily use even more advanced tools.

Find out more

High Flow Svivel

Our high-flow swivel provides even greater versatility for running high-flow tools. It can also be combined with an electrical swivel.

Find out more

HFC - High flow and tiltrotator – at the same

With our patented High Flow Controller (HFC), you can operate flow-intensive tools at the same times as a tiltrotator on just one circuit for hammer hydraulics.

Find out more

Sensors - Enable more smart functions

Built-in sensors give you access to even more functions. Home position and automatic calibration of hydraulic flow are two of them.

Find out more

Installation - Simple and easy with automatic calibration

To further improve tiltrotator capabilities, we have developed an automatic calibration system that optimises the tiltrotator according to the machine's hydraulics.

Operator settings - Easily switch between unique operator settings

The control system has space for four unique operator settings that you can easily switch between. With the push of a button, adjustments are made to the hydraulics and handle functions.

Display - Clear, simple with sturdy buttons

Handle everything easily via the display for both the control system and quick coupler. A simple and visual menu guides you through the options.

Joysticks - Easier control with same movement

Ergonomically designed handles allow you to control tilt, rotation and any extra function during the same excavation movement.

Find out more
